Built for immersive flying and everyday comfort, the BetaFPV VR04 Analog FPV Goggles are a great choice for hobby pilots who want a convenient, easy-to-use headset for analog FPV. The spacious, glasses-friendly design lets you keep your eyewear on, while the upgraded contoured face padding and soft rubber nose bridge help block outside light for a more focused and comfortable viewing experience. With a built-in 2000mAh battery, support for external 2–6S whoop battery input, and one-button DVR recording to microSD, the VR04 delivers the features you need for relaxed freestyle sessions, practice flights, and quick field use.

Key Features

• Glasses-friendly fit: Spacious interior allows comfortable use without removing your glasses.
• Improved light blocking: Contoured face foam and a soft nose bridge help reduce outside light for better immersion.
• Built-in 2000mAh battery: Up to around 2 hours of normal use, plus support for powering from a 2–6S whoop battery.
• One-button DVR recording: Save your flights directly to a microSD card and replay them anytime.
• 48-channel 5.8GHz support: Easy frequency search helps you quickly find an available analog channel.
• USB-C charging: Simple and modern charging for convenient everyday use.

Specifications

• Dimensions: 168.8 × 182.1 × 98.5 mm
• Weight: 425 g ±10 g
• Video format: NTSC / PAL
• Supported channels: 48CH
• Screen size: 4.3 inch
• Screen resolution: 800 × 480
• Battery: 3.7 V, 2000 mAh
• Operating time: approx. 2 hours normally, approx. 1 hour while recording
• Antenna connector: RP-SMA
• Charging port: USB-C
• Card slot: microSD (max. 64 GB, FAT32)
• Recording resolution: 480P@30fps
• Recorded video format: AVI

Product Diagram

Immersive Viewing and Long-Session Comfort

The VR04 goggles are designed for longer flying sessions without unnecessary discomfort. A glasses-compatible interior, quality PU foam, and a soft silicone nose bridge work together to create a snug fit while helping block distracting ambient light. It is a practical setup for hobby pilots who want to stay focused on the flight without overcomplicating their gear.

Flexible Power Options

The built-in 2000mAh battery provides up to around 2 hours of regular operation, making the VR04 a dependable option for casual flying at the field. When you need more flexibility, the goggles can also be powered directly from a 2–6S whoop battery, which is especially useful for longer sessions or quick battery swaps between flights.

Record and Replay Your Flights

With one-button recording, capturing your FPV footage is quick and simple. Just insert a microSD card up to 64 GB and save your flights directly in the goggles. It is an easy way to review practice runs, share clips with friends, or revisit your best moments without extra recording gear.

How to Record Video

• Insert a microSD card formatted in FAT32 (maximum 64 GB).
• Press the record button — a red dot will appear.
• Recording starts after approximately 8 seconds.
• Press the button again to stop recording.

Note: After starting recording, DVR activation may take around 8–10 seconds. The maximum file length is 10 minutes.

The goggles support 5.8GHz analog transmission and 48 channels. Press and hold the 5D button for 2–3 seconds to start frequency search. Signal color indicators:

• Green: channel available
• Yellow: moderate interference
• Red: channel occupied
• White: strongest signal

Compatibility

Aquila20 FPV Kit

What’s in the Box

• 1 × VR04 FPV Goggles
• 1 × Adjustable head strap
• 1 × User manual
