ToolkitRC M6DAC V2 Charger

ToolkitRC M6DAC V2 Charger

ToolkitRC M6DAC V2 is a compact yet seriously capable dual-channel RC battery charger designed for hobbyists who want high performance, flexible power options, and everyday convenience in one device. It’s a great match for RC cars, drones, planes, and other projects powered by popular battery packs.

With up to 200 W on AC input and up to 2 × 400 W on DC input, the M6DAC V2 gives you the power to charge efficiently at home, in the workshop, or out in the field. Its broad battery support, precise balancing, and extra features like USB-C fast charging and wireless charging make it much more than just a standard charger.

• Dual-channel charger with built-in AC power supply
• Charging power up to 200 W on AC
• Up to 2 × 400 W on DC or 700 W synchronous mode
• DC input range: 7–28 V
• Supports many battery types for versatile hobby use
• Balancing current up to 1 A
• High balancing accuracy: < 0.005 V
• Adjustable power supply mode with voltage and current control
• Compatible with smart batteries, including selected DJI-style packs
• USB-C fast charging up to 65 W with PD, QC, PPS, VOOC and more
• Wireless charging for mobile devices
• Metal control dial and clear 2.8-inch IPS LCD screen
• Active cooling with built-in fan

Supported Battery Types

• LiPo / LiHV / LiFe / Li-Ion / LTO: 1–6S
• NiMH: 1–16S
• Lead-acid batteries: 1–10S

Key Technical Specifications

• Input: AC 100–240 V / DC 7–28 V (max. approx. 32 A)
• Charging power: AC up to 200 W
• Charging power on DC: 2 × 400 W (up to 16 A) or 700 W synchronous mode (up to 28 A)
• Balancing: 1 A / accuracy < 0.005 V
• USB-C output: 65 W (20 V / 3.25 A), QC / PD / VOOC etc.
• Wireless charging: yes, approx. 10 W
• Display: 2.8″ IPS LCD, 320 × 240 px
• Dimensions: approx. 116 × 112 × 63 mm
• Weight: approx. 570 g

If you’re looking for a powerful, portable, and feature-packed RC charger, the ToolkitRC M6DAC V2 is an excellent choice. It combines strong charging performance, broad battery compatibility, and practical extras that hobby users will genuinely appreciate.
