Pilotix N2 Night FPV Camera

PILOTIX / FPV CAMERA
Pilotix N2 Night FPV Camera
The Pilotix N2 Night FPV camera performs well when flying in low-light conditions and after dark. Resolution 1500TVL and a black-and-white mode at an illumination level of 0,000001 lx allow you to capture detailed images in very dark conditions. Night mode sensitivity is 12400 mV/Lux-sec.
The compact housing measures 19x19 mm and accommodates a 1/2.8" CMOS sensor. The camera offers a wide dynamic range and configurable image settings.

Key features

Adjustable image and wide dynamic range
The wide dynamic range improves visibility in high-contrast scenes. The image format can be switched between 4:3 and 16:9, and the image can be set to color or black-and-white. The camera supports PAL/NTSC, automatic white balance, and a menu for adjusting basic functions.
POWER AND CONNECTIONS
5V-30V power range
The camera operates at a voltage of DC5V-30V and uses an M12 lens. The CVBS video output is configurable; the BT1120 output connects to HD video transmission.

OPERATING CONDITIONS
Temperature and humidity range
The camera is designed to operate at temperatures from -10°C to 50°C and at a relative humidity below 90%.
TECHNICAL SPECIFICATIONS
Technical specifications
| Type | N2 NIGHT |
| Sensor | CMOS 1/2.8" |
| Resolution | 1500TVL |
| Night mode sensitivity | 12400 mV/Lux-sec |
| Minimum illumination | 0,000001 lx (black-and-white, F1.6, 50IRE, AGC ON) |
| Field of view | FOVD: 125° H: 105° V: 55° |
| Lens | M12 |
| Signal-to-noise ratio | 50 dB |
| Video standard | PAL/NTSC selectable |
| Image format | 4:3 / 16:9 |
| Video output | CVBS; configurable BT1120 |
| Power supply | DC5V-30V |
| Operating temperature | from -10°C to 50°C |
| Operating humidity | relative humidity below 90% |
| Dimensions | 19x19 mm |
| EAN | 5061099730341 |
| Manufacturer's code | 7279 |
KIT CONTENTS
What's in the box
- 1 x Pilotix N2 Night FPV camera
