Kimpok Analog Video Receiver KP-R2200

Kimpok KP-R2200 - 2.2GHz Analog FPV Video Receiver

The Kimpok KP-R2200 is a compact analog VRX video receiver designed for FPV systems, drones, UAV platforms, and custom video transmission setups. Operating in the 2.2GHz band, it supports 8 channels across 2000-2280MHz, making it a great match for compatible analog transmitters working within the same frequency range.

If you are building a custom analog FPV setup outside the popular 5.8GHz band, the KP-R2200 is a practical choice. Its lightweight design, compact size, and wide 7-36V DC input range make it easy to use in mobile ground stations, long-range projects, UAV builds, and test platforms.

Built for 2.2GHz Analog FPV Systems

The standout feature of the Kimpok KP-R2200 is its operation in the 2.2GHz frequency band. It is made for hobbyists and builders who need a receiver for a specialized analog FPV system using transmitters in the 2000-2280MHz range. With the right video link setup, you can achieve a stable live image feed with the low latency that analog FPV is known for.

• Analog VRX video receiver for use with a compatible FPV video transmitter.
• 2.2GHz operation as an alternative to standard 5.8GHz FPV systems.
• 2000-2280MHz frequency range for matching analog transmitters in the same band.
• Low-latency analog video reception for real-time FPV viewing.
• Great for FPV and UAV projects, including drones, test rigs, and ground stations.

8 Channels for Flexible Frequency Matching

The KP-R2200 supports 8 reception channels, giving you more flexibility when matching your receiver to a specific transmitter, antenna, and RF environment. This is especially useful in custom FPV builds where every part of the system is selected individually, from the video transmitter and receiver to the antenna and display.

• 8 selectable channels for easier frequency setup.
• Designed for 2.2GHz transmitters in compatible analog video systems.
• Ideal for custom receiver stations used in FPV and UAV applications.
• Stable video reception when paired with the right antenna and proper system configuration.
• Well suited for long-range builds where a less common working frequency is preferred.

Compact, Lightweight, and Easy to Integrate

With dimensions of 45 x 27 x 28mm and a weight of only around 18.5g, the Kimpok KP-R2200 is easy to fit into a portable FPV setup, receiver case, or compact ground station. The wide 7-36V DC power input adds installation flexibility and makes the module suitable for various power sources commonly used in drone and RC projects.

• Approx. 18.5g weight for lightweight mobile FPV configurations.
• Compact 45 x 27 x 28mm size for installations where space matters.
• 7-36V DC input for flexible integration with different power systems.
• Made for DIY integration in custom analog FPV video links.
• A practical ground station component for receiving video from drones, RC models, or UAV platforms.

Technical Specifications

Package Contents and Recommended Use

The Kimpok KP-R2200 is a solid choice for hobbyists building a 2.2GHz analog FPV video link and looking for a lightweight receiver to pair with a compatible transmitter. It works well in long-range projects, UAV platforms, test benches, and portable receiving stations.

• Kimpok KP-R2200 Analog Video Receiver - 1 pc

Note: This receiver should be used with a transmitter operating in the same frequency range and with a properly matched antenna. Before use, make sure to verify frequency compatibility, power requirements, and overall system compliance with local radio regulations.
