FlyFishRC Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)
FlyFishRC Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)
FlyFishRC Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)
FlyFishRC Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)

FlyFishRC Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)

Producer:FlyFishRC
EAN:5907541600384
SKU:31184

Gross price:82,10 €

Net price:
66,71 €
Available
Available
30 days for free returns
Available stationary (Gdynia, PL)
FlyFishRC Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)
FlyFishRC Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)
Color:Black
Version:VX6
Sprawdź ofertę wynajmu
Wynajmij od 353 netto / mc

• Oferta dla klienta biznesowego

• Płacisz tylko za korzystanie

• Umowa na 12 miesięcy

• Faktura VAT

Color
Version
FlyFishRC Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)
82,10 €

Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)







Introducing Volador II – the new, improved 6” frame

We are excited to announce the second version of our Volador II frame! Thanks to numerous suggestions and feedback from users and testers of the V1 version (special thanks to Ryan Harrell and Kai Lin), we have made many optimizations to better suit the needs of FPV pilots.

Volador II maintains high compatibility and simple construction, and the set includes all necessary accessories to facilitate assembly and organization of components.



Two variants of the Volador II frame

  • Volador II VXSquashed X configuration, providing maximum control.
  • Volador II VDDeadcat configuration, eliminating propellers from the camera's view.

Both versions are compatible with a wide range of analog and HD systems available on the market. Thanks to the modular design and independently removable arms, the frame minimizes resonance, and the high-quality TPU elements ensure an aesthetic and neat assembly.

Volador II is the perfect choice for pilots who value perfect order in drone construction – it's the only frame on the market that allows for maximum aesthetic assembly of components.



Improvements in Volador II

Silicone vibration damping plate, specially designed for the DJI O3 Air Unit camera, eliminates the "jello" effect in DVR recordings. It is also compatible with 19 mm/20 mm cameras.

Top-quality materials – the frame is made of high-strength CNC aluminum and T700 carbon fiber. All edges are smoothly finished and beveled, preventing damage to wires and battery straps – and it looks great!

New anti-slip battery pad – features a grid for increased grip and stronger adhesive.

Integrated XT60 socket – protects power wires from propellers in case of a crash and allows for easy battery connection with one hand.

TPU elements – perfectly matched to the frame, increase its durability and look amazing. The Tropical Mix version is simply out of this world!



Key Features of Volador II V2

Top-class T700 carbon fiber
Design minimizing resonance
New CNC aluminum side plates – better camera protection
Silicone vibration dampers eliminating the "jello" effect in DJI O3 AU camera
Integrated XT60 socket for greater safety and convenience
High-quality TPU elements
New anti-slip battery pad
Motor wire guards
Compatibility with 19/20 mm cameras
Mounting kit for analog and HD systems
Grade 12.9 screws with factory Loctite
Wide compatibility with electronics



Major Changes in V2 Compared to V1

The frame is now significantly lighter
New CNC side plates are lighter and fit perfectly with the DJI O3 AU camera
New anti-slip battery pad – better grip and stronger adhesive
Added "keystone" – reduces arm vibrations
New pad under the bottom plate screws
Motor wire guards – better protection
Screws on the top plate are now countersunk – eliminating battery damage on impact
New lighter TPU arm guards – easier disassembly
Includes two versions of TPU antenna mounts (with GPS holder and without)
Adjusted thickness of the bottom and middle plate to 2.5 mm
Better stress distribution at the arm mounting point
New symmetrical XT60 hole – allows for mounting in both orientations



Volador II VX6 Specifications

  • Arm thickness: 6 mm
  • Top plate thickness: 2.5 mm
  • Middle plate thickness: 2.5 mm
  • Bottom plate thickness: 2.5 mm
  • Keystone thickness: 5 mm
  • Side plate thickness: 2 mm
  • CNC side plate thickness: 5 mm
  • Prop size: 6–6.1 inches
  • Material: T700 Carbon Fiber
  • FPV camera width: 19 mm / 20 mm
  • Weight: 188.2 g (with TPU elements)
  • Color: Black / Tropical Mix / Yellow (optional)
  • Overall dimensions: 209 mm × 159 mm
  • Wheelbase: 268 mm
  • Stack mounting: 20×20 mm / 30.5×30.5 mm (M3)
  • VTX mounting: 20×20 mm / 25.5×25.5 mm (M2)



Specification FlyFishRC Volador II VX6 O3 Deadcat FPV T700 Frame Set (Black)

Brand
FlyFishRC
Symbol
F000422
Producer code
5907541600384
Warranty
Startup
