FlyFishRC Volador II VD6 O4 Pro Deadcat FPV LR Freestyle T700 Frame (Yellow)

The FlyFishRC Volador II VD6 O4 Pro Deadcat is a refined 6-inch FPV frame designed for long-range and freestyle builds where clean layout, wide compatibility, and solid durability really matter. The Volador II series combines a simple, builder-friendly structure with all the essential accessories needed for an easy, tidy, and convenient assembly.

The VD6 version uses the popular Deadcat layout, helping keep propellers out of the camera view while maintaining excellent flight characteristics. It supports a wide range of analog and digital FPV systems, and its independently removable arms plus compact structure help reduce frame resonance for a cleaner, more locked-in flying feel. Carefully designed TPU parts improve both protection and cable management, making it easier to create one of the cleanest-looking builds in your fleet.

This version is also optimized for the DJI O4 Air Unit, featuring a silicone camera damping insert designed to reduce jello in DVR footage. At the same time, it remains compatible with 19 mm / 20 mm cameras, giving builders more flexibility when choosing their setup.

The frame is made from high-quality T700 carbon fiber plates and high-strength CNC-machined aluminum parts. Smooth plate finishing and evenly chamfered edges help protect wires and battery straps from damage, while also giving the frame a premium look and feel.

The redesigned battery pad with added mesh texture delivers improved anti-slip performance and uses a stronger adhesive. An integrated rear XT60 mount helps protect power leads from prop strikes in crashes and makes one-handed battery connection easier and more convenient.

The kit includes the accessories needed for both analog and HD builds, along with pre-applied thread-locking screws for improved reliability. A lot of attention has also gone into the TPU parts, which fit the frame perfectly, add durability, and give the build a sharp, polished finish.

Key Features

• 6-inch Deadcat FPV frame for long-range and freestyle builds
• Prop-free camera view thanks to the Deadcat geometry
• Premium T700 carbon fiber construction
• Compact design that helps minimize resonance
• CNC aluminum camera side plates for improved camera protection
• Silicone dampers for DJI O4 Air Unit to reduce jello in DVR footage
• Integrated XT60 mount for safer and cleaner power lead routing
• High-quality TPU components for protection and a cleaner build layout
• Improved anti-slip battery pad with stronger adhesive
• Motor wire protection tubes included
• Compatible with 19 mm / 20 mm FPV cameras
• Includes accessories for both analog and HD setups
• Class 12.9 screws with pre-applied thread locker
• High compatibility with modern FPV electronics

What’s New in V2

• Noticeably lighter frame design
• New lighter CNC side plates better matched to the DJI O4 Air Unit
• New battery pad with improved grip
• Added keystone element to reduce arm vibration
• Added washers for bottom screws
• Added motor wire protection tubes
• Flush-mounted top plate screws to help protect the battery in crashes
• New TPU arm guards are lighter and easier to remove
• All models include two TPU antenna mount options, with or without GPS mount
• Updated top, middle, and bottom plate thickness to 2.5 mm
• Reworked arm-to-clamp plate connection for better stress distribution
• Symmetrical XT60 cutout in the top plate for reversible mounting

VD6 Specifications

• Arm thickness: 6 mm
• Top plate thickness: 2.5 mm
• Middle plate thickness: 2.5 mm
• Bottom plate thickness: 2.5 mm
• Keystone thickness: 5 mm
• Side plate thickness: 2 mm
• CNC side plate thickness: 5 mm
• Propeller size: 6 ~ 6.1 inch
• Material: T700 carbon fiber plates
• FPV camera width: 19 mm / 20 mm
• Weight: 200 g (with TPU parts)
• Color: Black / Tropical Mix (optional)
• Overall dimensions: 259 mm × 109 mm
• Wheelbase: 260 mm
• Flight stack mounting: 20 × 20 mm / 30.5 × 30.5 mm (M3)
• VTX mounting: 20 × 20 mm / 25.5 × 25.5 mm (M2)
• Motor mounting: 16 × 16 mm (φ3 mm)

In the Box

• 1 × Volador II VD6 frame kit
