DC 7-28V ToolkitRC M7 LiPo 1-6S 10A charger
Drone service
Helpful
Reliability
Trust
Own warehouse & showroom
Warranty
53,29 €
DC Charger 7-28V ToolkitRC RC M7 LiPo 1-6S 10A
The M7 charger is smaller, lighter and almost as powerful as the M7AC charger. With many different functions such as balance loading and unloading. However, it can also be used as a signal measuring device or directly as a signal source for PWM, PPM and SBUS signals.
Characteristics:
- Charging power up to 300W and a maximum charging current of 15A
- Max discharge power 300W
- All-in-one
- Charger
- Voltage, resistance, PWM/PPM/SBUS signal meter
- Reproducing PWM/PPM/SBUS signals
- Multilingual user interface including voice output
- Upgradable via USB
- Various security checks
Technical Specifications:
| Input voltage: | AC 100-240V, Max 100W DC 7-35V, Max 20A |
| Charging power: | 0.1-15A, 300W |
| discharge power: | 0.1-15A, 300W (Recording Mode/External) 0.1-3A, 15W (internal mode) |
| Charging Accuracy: | <0.005V |
| USB A: | 5.0V @ 10W (or upgrade) |
| Balance current: | 800mA, 4.2V |
| LiPo/LiFe/LiIon/LiHV cells | 1-6S |
| Cells: NiMH/NiCd | 1-16S |
| Pb battery voltage: | 1-10S |
| Tension: | 1.0V-5.0V, 1-6S |
| Display: | 2.4'' IPS display 320x240 pixels |
| TF card: | It supports from 128MB to 16GB |
| Dimensions: | 112x73x38mm |
| Libra: | 245g |
Measurement and output:
| Measurement | PWM | 880us-2200us, 20-400hz |
| PPM | 880us-2200us x8 channels, 20-50Hz | |
| SBUS | 880us-2200us x16 channels, 20-100hz | |
| Exit | PWM | 500us-2500us, 20-1000hz |
| PPM | 880us-2200us x8 channels, 50Hz | |
| SBUS | 880us-2200us x16CH, 74hz | |
| Power | 0.5-15A, 1-28V, mode: CC+CV |
Included
- 1x M7AC charger
- 1x USB cable
- 1x User Manual
Specification DC 7-28V ToolkitRC M7 LiPo 1-6S 10A charger
Brand
ToolkitRC
Symbol
TK11400
Producer code
6972969830063
Translations
eng
ukr
